SG-D500M aluminum pendant automatic cutting saw
Product introduction: Product introduction
The machine is mainly used for cutting aluminum curtain wall
pounders, heat dissipation panels and industrial aluminum profiles.
High-power direct motor reduces the rotating loss of belt, and
gas-liquid stepless feed cutting through linear guide rail. The
cutting speed is fast and accurate, the imported numerical control
positioning system is adopted, the adjustment is simple and
convenient, it is the ideal equipment to improve the cutting
precision and production efficiency.
Technique data
1, the machine power supply power... Three phase 380 v / 50 hz
2, motor power Blade motor... 7.5 KW
3, motor speed blade rotary speed... 2840r/ min
4, maximum feed bean travelling... 1500mm
5 Min, minimum cutting length cutting length... 4mm
6, excess stock length Clout length... 80mm
7, retainer frame Length, Length of the location frame... 5000mm
8, positioning precision positioning how... + / - 0.05 mm
9, cutting size (WXH) cutting the size... 300mmX150mm
10. Cutting Angle................ 90° (Angular offset≤5 points
11, the size of the saw blade saw blade... X120t Ø 500 mmx30x4. 2
12, the Feeding speed bean speed... 20m/min
13, the size of the feed cylinder bean servo power... Ø 63 x400
14, blade feeding speed................... 0-10m/min
15, machine pneumatic air pressure... 0.6-0.8 Mpa
16, cutting cooling cooling... Atomization cooling/circulating
cooling of cutting fluid
17, touch Screen size Screen size... 7inches
18 machine, machine weight weight... 800kg
21, Machine size (L X W X H).................2000mmX900mmX1800mm
